AV MANTA G-2460B POE
SKU#:
51495
Flexible GigE Vision cameras with rich functionality.
Note: Actual product may vary from image!
You can find downloads in the corresponding product series:
Allied Vision - Manta
List Price
Your Discount
Your Price
€2,630.00
Product not available in your country
Price & Availability on Request
Contact us
Request prices
Errors and changes excepted. Our general terms and conditions apply. We supply exclusively to corporate customers.
Product Features
| Attributes | |
|---|---|
| Wavelength range | Monochrome, Visible |
| Resolution (MP) | 24.6 |
| Frame rate (Hz) | 4.9 |
| Lens mount | C-Mount |
| Interface | Gigabit Ethernet |
| Interface configuration | 1 GigE, GigE Vision, PoE |
| Sensor model | IMX540 |
| Active sensor size (horizontal, mm) | 14.58 |
| Active sensor size (vertical, mm) | 12.6 |
| Bit depth | 12 |
| Certificates | CE |
| Connector a: video | RJ45 - (H) - Female |
| Connector b: power | Hirose 12-pin |
| Connector c: I/O | Hirose 12-pin |
| Digitalisation | 12 bit A/D-converter |
| Dimension (depth, mm) | 86.4 |
| Dimension (height, mm) | 29 |
| Dimension (width, mm) | 44 |
| Flange focal distance | 17.526 |
| Resolution Horizontal (Px) | 5328 |
| Housing | standard |
| Numbers of connectors (Video) | 1 |
| Output formats | Mono12, Mono12Packed, Mono8 |
| Pixel size (µm) | 2.74 |
| Power consumption (W) | 3.3 |
| Power supply voltage (VDC) | 8 - 30 |
| Scan type | area |
| Sensor format | 1.2" |
| Sensor size diagonal (mm) | 19.3 |
| Sensor type | CMOS |
| Shutter type | Global shutter |
| Software CameraSuite | yes |
| Resolution Vertical (Px) | 4608 |
| Weight (kg) | 0.190 |
- Resolution from VGA to 24 megapixel, up to 286 fps
- Bit depth: 8 or 12 bit
- Interface: Gigabit Ethernet, GigE Vision, up to 128 MB resend buffer
- Power supply: available as Power over Ethernet (PoE) version
