SCHNEIDER THULITE 2.8/35 TFL

SKU#: 55961

Large-format lenses for the VIS and NIR range

Note: Actual product may vary from image!

You can find downloads in the corresponding product series:

Schneider-Kreuznach - THULITE
Contact us Request prices

Errors and changes excepted. Our general terms and conditions apply. We supply exclusively to corporate customers.

Product Features

Attributes
Focal length (mm) 35
Sensor format APS-C
Sensor size diagonal (mm) 32
Camera mount (optics) TFL-Mount
Min. pixel size 2.4 µm
Aperture F 2.8 - F 16
M.O.D. (mm) 200
Wavelength range Visible
Diameter (mm) 56
Filter thread M43 x 0.75
Length (mm) 41
Magnification (max) N/A
Resolution N/A
  • Sensor size: up to 2"
  • Image circle: 32 mm
  • Resolution: up to 2.4µm pixel size
  • Focal length: 35 mm, 50 mm, 75 mm
  • Camera mount: M41 x1, M42 x 0.75, TFL
  • Aperture: F2.8 to F16
  • Aperture control: Manual
  • Working distance: covers a wide range
  • Focus control: Manual
  • Wavelength range: Broadband coating (up to 1000nm)
  • Filter size: M43 x 0.75 (35mm, 50mm), M46 x 0.75 (75mm)
