SONY FCB-ER8550
SKU#:
38298
Full HD and 4K OEM camera modules with integrated zoom lenses
Note: Actual product may vary from image!
You can find downloads in the corresponding product series:
Sony - FCB
Contact us
Request prices
Errors and changes excepted. Our general terms and conditions apply. We supply exclusively to corporate customers.
Product Features
| Attributes | |
|---|---|
| Active sensor size (horizontal, mm) | 6.22 |
| Active sensor size (vertical, mm) | 3.5 |
| Bit depth | 8 |
| Certificates | No CE, No Dual Use |
| Dimension (depth, mm) | 93 |
| Dimension (height, mm) | 60 |
| Dimension (width, mm) | 50 |
| Frame rate (Hz) | 30 |
| Resolution Horizontal (Px) | 3840 |
| Housing | OEM module |
| Interface | HDMI |
| Interface configuration | N/A |
| Lens mount | None |
| Operating temperature (°C) | -5 - 60 |
| Pixel size (µm) | 1.62 |
| Power supply voltage (VDC) | 6 - 12 |
| Resolution (MP) | 8.5 |
| Scan type | area |
| Sensor configuration | Single sensor |
| Sensor format | 1/2.5" |
| Sensor model | IMX274 |
| Sensor size diagonal (mm) | 7.2 |
| Sensor type | CMOS |
| Shutter type | Rolling shutter |
| Software CameraSuite | no |
| Software driver CVB | no |
| Wavelength range | Colour, Visible |
| Storage temperature (°C) | -20 - 60 |
| Resolution Vertical (Px) | 2160 |
| Weight (kg) | 0.270 |
- Sensor: latest Sony Exmor R CMOS
- Resolution: up to 4K
- Frame rate: up to 60 fps
- Lens: up to 70.4 degree HFOV, 20x / 30x zoom ratio, autofocus
- Interface: HDMI 1.4b video output
