Computar - MPX
High-resolution, compact Computar MPX C-mount lenses: support up to 16 MP on 2/3″ sensors, ultra-low distortion, floating focus, rugged with 10 G shock/vibration resistance.
Key Features
- Sensor size: up to 2/3"
- Image Circle: 11.8mm
- Resolution: 16 MP, support 2µm pixel pitch
- Focal length: 8, 12, 16, 25, 35, 50, 75mm
- Camera mount: C-Mount
- Distortion: <|0.25|% (varies by model)
- Aperture: F2.8 to F16.0 (except M7538-MPX: F3.8)
- Aperture Control: Manual (Click-iris)
- Working Distance: 0.1m to Infinity (MOD varies by model)
- Focus Control: Manual, high precision (5x wider angle)
- Wavelength Range: VIS (400-700nm)
- Mechanical: Anti-vibration (10G) and shock resistance (10G)
- Filter size: M30x0.5
- Length: <46mm
- Diameter: 31.8mm (uniform)
- Weight: <89g
Find the right model for your needs
Use the filters below to narrow down your selection based on your application requirements
| Nombre del producto | Focal length (mm) | Sensor size diagonal (mm) | Min. pixel size | Aperture | Wavelength range | M.O.D. (mm) | Camera mount (optics) | Manufacturer | Filter thread | Magnification (max) | Resolution | Sensor format |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 8 | 11.8 | 2.1 µm | F 2.8 - F 16 | Visible | 100 | C-Mount | Computar | M30.5 x 0.5 | N/A | 16 | 2/3" | |
| 12 | 11.8 | 2.1 µm | F 2.8 - F 16 | Visible | 100 | C-Mount | Computar | M30.5 x 0.5 | N/A | 16 | 2/3" | |
| 25 | 11.8 | 2.1 µm | F 2.8 - F 16 | Visible | 76 | C-Mount | Computar | M30.5 x 0.5 | N/A | 16 | 2/3" | |
| 35 | 11.8 | 2.1 µm | F 2.8 - F 16 | Visible | 130 | C-Mount | Computar | M30.5 x 0.5 | N/A | 16 | 2/3" | |
| 50 | 11.8 | 2.1 µm | F 2.8 - F 16 | Visible | 190 | C-Mount | Computar | M30.5 x 0.5 | N/A | 16 | 2/3" | |
| 75 | 11.8 | 2.1 µm | F 3.8 - F 16 | Visible | 246 | C-Mount | Computar | M30.5 x 0.5 | N/A | 16 | 2/3" |
