Teledyne FLIR - Forge 1 GigE IP67
The Forge 1GigE IP67 camera is engineered for industrial imaging excellence, combining robust performance with a compact design. Operating seamlessly in harsh environments, it features advanced Sony Pregius sensors delivering resolutions up to 5 Megapixel. With reliable IP67 ingress protection, users can trust its durability and easy integration. Perfect for OEMs and system integrators looking to enhance their existing 1GigE setups, the Forge redefines cost-effective performance without compromising quality.
Key Features
- Ingress Protection: IP67 for reliable operation in harsh environments
- Small IP67 body for easy integration
- High-speed performance with advanced imaging features
- Data interface: 1 Gbit/s Ethernet
- Optimized enclosure: Designed for easy post-operation cleaning
- Sensor type: CMOS (Sony Pregius)
- Power over Ethernet (PoE) support
- Versatile applications: Ideal for various industrial imaging needs
- Full Ecosystem: Variety of accessories available
Find the right model for your needs
Use the filters below to narrow down your selection based on your application requirements
| Nombre del producto | Dimension (depth, mm) | Dimension (height, mm) | Dimension (width, mm) | Frame rate (Hz) | Resolution Horizontal (Px) | Housing | Interface | Lens mount | Manufacturer | Pixel size (µm) | Resolution (MP) | Scan type | Sensor format | Sensor model | Sensor size diagonal (mm) | Sensor type | Shutter type | Wavelength range | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 44 | 55 | 44 | 24 | 2448 | Compact | Gigabit Ethernet | C-Mount | Teledyne FLIR | 3.45 | 5 | area | N/A | IMX264 | 8.9 | CMOS | Global shutter | Monochrome; Visible | 0.130 | |
| 44 | 55 | 44 | 24 | 2448 | Compact | Gigabit Ethernet | C-Mount | Teledyne FLIR | 3.45 | 5 | area | N/A | IMX264 | 8.9 | CMOS | Global shutter | Colour; Visible | 0.130 |
