Vieworks - VN
Pixel shift cameras designed for applications with stationary objects requiring an extremely high resolution.
Key Features
- Sensor: ON Semiconductor VITA-25k CMOS image sensor, monochrome or colour
- Resolution: 25 megapixel (standard) up to 236 megapixel (extended resolution)
- Features: nano-stage pixel shift mechanism, improved fill factor, flat field correction, field-upgradable firmware, pixel defect correction
- Lens mount: F-mount
- Interface: CoaXPress
Find the right model for your needs
Use the filters below to narrow down your selection based on your application requirements
| Nombre del producto | Bit depth | Dimension (depth, mm) | Dimension (height, mm) | Dimension (width, mm) | Frame rate (Hz) | Resolution Horizontal (Px) | Housing | Interface | Interface configuration | Lens mount | Manufacturer | Pixel size (µm) | Resolution (MP) | Scan type | Sensor configuration | Sensor model | Sensor size diagonal (mm) | Shutter type | Wavelength range | Resolution Vertical (Px) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 10; 8 | 150 | 80 | 80 | 72 | 5120 | standard | CoaXPress | 2x CXP-6; 4x CXP-6 | Nikon F-Mount | Vieworks | 4.5 | 25 | area | Pixel shift sensor | VITA 25K | 32 | Global shutter/Prog scan | Colour; Visible | 5120 | 1.100 | |
| 10; 8 | 150 | 80 | 80 | 72 | 5120 | standard | CoaXPress | 2x CXP-6; 4x CXP-6 | Nikon F-Mount | Vieworks | 4.5 | 25 | area | Pixel shift sensor | VITA 25K | 32 | Global shutter/Prog scan | Monochrome; Visible | 5120 | 1.100 |
