Vieworks - VX
A powerful camera specifically engineered for aerial imaging and ground surveillance applications, equipped with a high-resolution 25 million pixel sensor and a Canon EF lens controller.
Key Features
- Sensor: high-performance progressive-scan CMOS
- Resolution: 25 megapixels
- Bit depth: 8,10 or 12 bit data output
- Frame rate: 2.3 fps
- Interface: GigE Vision
- Features: auto focus, auto exposure, auto gain, auto aperture control using Canon EF controller, defect pixel correction, anti-blooming, anti-smear
Find the right model for your needs
Use the filters below to narrow down your selection based on your application requirements
| Nombre del producto | Wavelength range | Resolution (MP) | Resolution Horizontal (Px) | Resolution Vertical (Px) | Frame rate (Hz) | Lens mount | Interface | Sensor model | Sensor type | Scan type | Pixel size (µm) | Sensor format | Sensor size diagonal (mm) | Shutter type | Dimension (width, mm) | Dimension (height, mm) | Dimension (depth, mm) | Housing | Weight (kg) | Manufacturer |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Monochrome; Visible | 25 | 5120 | 5120 | 4.7 | M42 x 1; Nikon F-Mount | Gigabit Ethernet | VITA 25K | CMOS | area | 4.5 | 35mm | 1.8 | Global shutter/Prog scan | 68 | 68 | 80 | standard | 0.420 | Vieworks |
¿Por qué elegir Vieworks - VX?
Optimal Solution for Outdoors
VX Series is a robust camera series that has undergone strict reliability tests such as 10G vibration test and 70G shock test. In addition, the camera operating temperature is from -50 degrees Celsius to 80 degrees Celsius which makes it is suitable for outdoor machine vision applications.
Easy Control
Using functions such as auto exposure, auto focus, auto gain, it is easy to control the camera outdoors.
Better Usability
Programmable camera makes it easy to update the firmware in the field. VX Series supports Gigabit Ethernet interface and provides the image processing like FFC(Flat Field Correction), Pixel defect correction and Anti-smear.
