Pleora - External Grabber
Upgrade legacy camera systems with high-performance GigE Vision and USB3 Vision connectivity using advanced external frame grabbers. Stream real-time, low-latency video from Camera Link and analog cameras directly to processors and displays—while leveraging long-distance Ethernet cabling, networking, and multicasting advantages.
Key Features
- External frame grabber for sensor-to-processor and display interface conversion
- Supports Camera Link (Base, Medium, Full) and analog camera input
- Converts Camera Link to Gigabit Ethernet for system modernization
- Video signal outputs: GigE Vision, USB3 Vision, Thunderbolt, HDMI and DVI
- Long-distance, flexible Ethernet cabling for industrial environments
- Networking & multicasting capabilities for multi-user access
- Real-time, low-latency video streaming
- Integrated control, synchronization & triggering of system components
- Maintains native camera streaming and control functionality
- Roadmap architecture optimized to reduce CPU usage for high-bandwidth imaging
Find the right model for your needs
Use the filters below to narrow down your selection based on your application requirements
| Nom de produit | Connectors | Dimension (depth, mm) | Dimension (height, mm) | Dimension (width, mm) | Inputs | Interface | Interface/Standard | Manufacturer | Number channels | Onboard memory (MB) | Onboard processing | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1* SDR | 83 | 51 | 38 | Base | USB3 Vision | CameraLink | Pleora | 1 | 120 | no | N/A | |
| 2* SDR | 83 | 51 | 38 | Medium | USB3 Vision | CameraLink | Pleora | 1 | 120 | no | N/A | |
| 2* SDR | 83 | 51 | 38 | Medium | USB3 Vision | CameraLink | Pleora | 1 | 120 | no | N/A | |
| 2* SDR | 83 | 51 | 38 | Medium | USB3 Vision | CameraLink | Pleora | 1 | 120 | no | 0.137 | |
| 1* SDR | 83 | 51 | 38 | Base | USB3 Vision | CameraLink | Pleora | 1 | 120 | no | 0.134 | |
| 1* SDR | 83 | 51 | 38 | Base | USB3 Vision | CameraLink | Pleora | 1 | 120 | no | N/A | |
| 1* SDR | 83 | 51 | 38 | Base | USB3 Vision | CameraLink | Pleora | 1 | 120 | no | 0.133 | |
| 2* SDR | 83 | 51 | 38 | Medium | USB3 Vision | CameraLink | Pleora | 1 | 120 | no | 0.136 | |
| 1* SDR | 47.6 | 51 | 81.5 | Base | Gigabit Ethernet | CameraLink | Pleora | 1 | 120 | no | 0.162 | |
| 1* SDR | 47.6 | 51 | 81.5 | Base | Gigabit Ethernet | CameraLink | Pleora | 1 | 120 | no | N/A | |
| 1* SDR | 47.6 | 51 | 81.5 | Base | Gigabit Ethernet | CameraLink | Pleora | 1 | 120 | no | 0.047 | |
| 1* SDR | 47.6 | 51 | 81.5 | Base | Gigabit Ethernet | CameraLink | Pleora | 1 | 120 | no | 0.047 | |
| 1* SDR | 83 | 51 | 38 | Base | USB3 Vision | CameraLink | Pleora | 1 | 120 | no | 0.039 | |
| 2* SDR | 83 | 51 | 38 | Medium | USB3 Vision | CameraLink | Pleora | 1 | 120 | no | 0.042 |
Pourquoi choisir Pleora - External Grabber ?
Extend the Life of Legacy Systems
Convert existing Camera Link cameras to GigE Vision or USB3 Vision to protect prior investments while enabling modern connectivity and performance upgrades.
Future-Proof System Designs
Upgrade to 1 GigE or 10 GigE infrastructure to support higher bandwidth imaging and scalable architectures without replacing proven cameras.
Flexible Installation & Long-Distance Operation
Use cost-effective Ethernet cabling to place processors and displays far from harsh manufacturing environments, improving reliability and serviceability.
Reduced System Load & Higher Performance
Optimized hardware architecture lowers CPU usage, enabling smoother real-time image processing in high-bandwidth applications.
Seamless Integration with Full System Control
Maintain native camera streaming, triggering, synchronization, and control functions—ensuring deterministic, low-latency performance across the entire vision system.
