Z-Laser - ZX20
The ZX20 laser module stands out for its precision, offering an industry-leading boresight error typically < 0.8 mrad (fixed focus). Its automated production ensures perfect alignment of optical components, resulting in high-precision illumination for machine vision applications. With tool-free manual focus adjustment, users can adapt the laser projection to different working distances. Its robust design is suitable for industrial environments, making it reliable even under harsh conditions.
Key Features
- Wavelength: 405, 450, 520, 635, 640, 660, 830 nm
- Laser precision: boresight error typ. 0.8 mrad (fixed focus), line orientation < 10 mrad, pointing stability < 10 µrad/K
- Lens: various projection patterns
- Working distance: 100 mm to 10.000 mm
- Features: simple hand focusing mechanism, fault control with LED codes, internal storage of temperature, uptime and other parameters (model dependent), APC function for constant light output
- I/O: analogue and TTL modulation, up to 400 kHz (model dependent)
- Output power: Up to 200 mW (model dependent)
- Power: stability +/- 3% over operating temperature range (24 h), < 5% over lifetime
- Interface: I2C, UART (5V)
- Power supply: 405 nm - 520 nm: 9 - 30 VDC, 15 VA 635 nm - 830 nm: 5 - 30 VDC, 15 VA
- Protection class: IP67
- Mounting: 20 mm mount (alternative M18-thread)
Find the right model for your needs
Use the filters below to narrow down your selection based on your application requirements
| Nom de produit | IP rating | Manufacturer |
|---|---|---|
| IP67 | Z-Laser | |
| IP67 | Z-Laser | |
| IP67 | Z-Laser | |
| IP67 | Z-Laser | |
| IP67 | Z-Laser | |
| IP67 | Z-Laser | |
| IP67 | Z-Laser | |
| IP67 | Z-Laser | |
| IP67 | Z-Laser | |
| IP67 | Z-Laser | |
| IP67 | Z-Laser | |
| IP67 | Z-Laser | |
| IP67 | Z-Laser | |
| IP67 | Z-Laser | |
| IP67 | Z-Laser |
