Schneider-Kreuznach - ONYX
Extremely fast 1" C-mount lens - perfect for low-light and high-speed applications.
Key Features
- Maximum image circle: 16 mm
- Focal length: 25 mm
- Aperture: F0.95
- M.O.D.: 133 mm
- Filter thread: M39 x 0.5
- Interface: C-mount
- Miscellaneous: Lockable focus and iris setting
Find the right model for your needs
Use the filters below to narrow down your selection based on your application requirements
| Nome do produto | Aperture | Camera mount (optics) | Filter thread | Focal length (mm) | Magnification (max) | Manufacturer | Min. pixel size | M.O.D. (mm) | Resolution | Sensor format | Sensor size diagonal (mm) | Wavelength range |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| F 0.95 | C-Mount | M39 x 0.5 | 25.6 | 0.100 | Schneider Kreuznach | 7 µm | 150 | 3.0 - 5.0 | 1" | 15.8 | Visible | |
| F 0.95 | C-Mount | M39 x 0.5 | 25.6 | 0.100 | Schneider Kreuznach | 7 µm | 150 | 3.0 - 5.0 | 1" | 15.8 | Visible |
