Smart Vision Lights - LTF Linear Light
The LTF (Linear Tunable Field Of View) series features three independently adjustable beam angle light channels. This allows the channels to be switched and mixed to adjust working distance and illumination angle.
Key Features
- Three independent lighting channels with adjustable beam angles
- 5 lens options featuring 10°, 30° and 50° angle of aperture
- Multi-Drive function enables continuous or OverDrive strobe operation
- Access remote intensity control via the SmartVisionLink app
- Integrated strobe input built into the driver
- Available in white, blue, green, red and NIR colours.
- Four different lengths available: 300mm, 600mm, 900mm, and 1200mm.
- Provides IP65 protection for harsh environments.
Find the right model for your needs
Use the filters below to narrow down your selection based on your application requirements
| Nome do produto | Beam angle | Connectors | Dominant wavelength (nm) | Emitting surface height (mm) | Emitting surface inner diameter (mm) | Emitting surface outer diameter (mm) | Emitting surface width (mm) | Intensity control method | IP rating | LED risk group | Light colour | Light distribution | Lighting geometry | Lighting technique | Manufacturer | Smart | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| medium | N/A | 530 | 40 | N/A | N/A | 290 | Multidrive | IP65 | 1 | Green | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 0.816 | |
| medium | N/A | 395 | 40 | N/A | N/A | 290 | Multidrive | IP65 | 1 | UV | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 0.816 | |
| medium | N/A | 940 | 40 | N/A | N/A | 290 | Multidrive | IP65 | 1 | IR | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 0.816 | |
| medium | N/A | 625 | 40 | N/A | N/A | 866 | Multidrive | IP65 | 1 | Red | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 2.170 | |
| medium | N/A | 530 | 40 | N/A | N/A | 578 | Multidrive | IP65 | 1 | Green | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 1.450 | |
| medium | N/A | 625 | 40 | N/A | N/A | 578 | Multidrive | IP65 | 1 | Red | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 1.450 | |
| medium | N/A | 470 | 40 | N/A | N/A | 578 | Multidrive | IP65 | 1 | Blue | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 1.450 | |
| medium | N/A | 850 | 40 | N/A | N/A | 290 | Multidrive | IP65 | 1 | IR | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 0.816 | |
| medium | N/A | N/A | 40 | N/A | N/A | 578 | Multidrive | IP65 | 1 | White | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 1.450 | |
| medium | N/A | 470 | 40 | N/A | N/A | 290 | Multidrive | IP65 | 1 | Blue | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 0.816 | |
| medium | N/A | 850 | 40 | N/A | N/A | 578 | Multidrive | IP65 | 1 | IR | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 1.450 | |
| medium | N/A | 940 | 40 | N/A | N/A | 578 | Multidrive | IP65 | 1 | IR | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 1.450 | |
| medium | N/A | 470 | 40 | N/A | N/A | 866 | Multidrive | IP65 | 1 | Blue | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 2.170 | |
| medium | N/A | 530 | 40 | N/A | N/A | 866 | Multidrive | IP65 | 1 | Green | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 2.170 | |
| medium | N/A | 850 | 40 | N/A | N/A | 866 | Multidrive | IP65 | 1 | IR | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 2.170 | |
| medium | N/A | 940 | 40 | N/A | N/A | 866 | Multidrive | IP65 | 1 | IR | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 2.170 | |
| medium | N/A | 470 | 40 | N/A | N/A | 1154 | Multidrive | IP65 | 1 | Blue | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 2.950 | |
| medium | N/A | 530 | 40 | N/A | N/A | 1154 | Multidrive | IP65 | 1 | Green | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 2.950 | |
| medium | N/A | 625 | 40 | N/A | N/A | 1154 | Multidrive | IP65 | 1 | Red | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 2.950 | |
| medium | N/A | 850 | 40 | N/A | N/A | 1154 | Multidrive | IP65 | 1 | IR | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 2.950 | |
| medium | N/A | 940 | 40 | N/A | N/A | 1154 | Multidrive | IP65 | 1 | IR | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 2.950 | |
| medium | N/A | 625 | 40 | N/A | N/A | 290 | Multidrive | IP65 | 1 | Red | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 0.816 | |
| medium | N/A | 365 | 40 | N/A | N/A | 290 | Multidrive | IP65 | 1 | UV | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 0.816 | |
| medium | N/A | N/A | 40 | N/A | N/A | 290 | Multidrive | IP65 | 1 | White | direct | bar light; line light | frontlight | Smart Vision Lights | yes | N/A | |
| medium | N/A | N/A | 40 | N/A | N/A | 866 | Multidrive | IP65 | 1 | White | direct | bar light; line light | frontlight | Smart Vision Lights | yes | N/A | |
| medium | N/A | N/A | 40 | N/A | N/A | 1154 | Multidrive | IP65 | 1 | White | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 2.950 | |
| medium | N/A | N/A | 40 | N/A | N/A | 290 | Multidrive | IP65 | 1 | White | direct | bar light; line light | frontlight | Smart Vision Lights | yes | 0.816 |
Por que escolher Smart Vision Lights - LTF Linear Light?
Three independently tunable beam angle channels
Lightning channels with different opening angle, optimizable for many different applications over a wide range of working distances and field of view requirements.
Various lens configurations for flexible usage
5 lens configurations with 10°, 30° and 50° opening angle offer a flexible usage. Please ask for the possible configurations
Easy remote intensity adjustment
When used with the BTM-1000 Bluetooth and the SmartVisionLink app, lighting channels can be set remote very easily
Intensity control for continuous and overdrive operation
The Multi-Drive function allows continuous or OverDrive strobe operation
