Xenics - Gobi Plus
Affordable LWIR infrared camera with uncooled micro bolometer for thermal imaging providing high sensitivity and image resolution.
Key Features
- Sensor: uncooled microbolometer (a-Si) with array operability >99%, rolling shutter
- Resolution: 640 x 480 pixels
- Frame rate: up to 60 Hz (full frame)
- Responsitivity: 8–14 µm
- Features: non-uniformity correction via DSP, several gain modes
- I/O: LV CMOS (low voltage V Schmitt-trigger input)
- Interface: CameraLink or GigE Vision (PoE)
- Camera Configuration: fully GenICam compliant; using Xenics Xeneth Software or any other SDK
- Operating temperature: -40°C to 60°C
- Protection: high shock and vibration resistance
Find the right model for your needs
Use the filters below to narrow down your selection based on your application requirements
| Nome do produto | Dimension (depth, mm) | Dimension (height, mm) | Dimension (width, mm) | Frame rate (Hz) | Resolution Horizontal (Px) | Housing | Interface | Lens mount | Manufacturer | Pixel size (µm) | Resolution (MP) | Scan type | Sensor format | Sensor model | Sensor size diagonal (mm) | Sensor type | Shutter type | Wavelength range | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 62 | 49 | 49 | 60 | 640 | standard | CameraLink | M35 x 0.75; M42 x 1 | Xenics | 17 | 0.3 | area | N/A | Microbolometer | 13.6 | N/A | Rolling shutter | LWIR | 0.210 | |
| 80 | 49 | 49 | 60 | 640 | standard | Gigabit Ethernet | M35 x 0.75; M42 x 1 | Xenics | 17 | 0.3 | area | N/A | Microbolometer | 13.6 | N/A | Rolling shutter | LWIR | 0.264 | |
| 80 | 49 | 49 | 9 | 640 | standard | Gigabit Ethernet | M35 x 0.75; M42 x 1 | Xenics | 17 | 0.3 | area | N/A | Microbolometer | 13.6 | N/A | Rolling shutter | LWIR | 0.264 |
