Vieworks - VC

Ultra high-speed machine vision cameras, based on global shutter CMOS sensors with frames rates up to 450fps.

Key Features

  • Sensor: high speed CMOS sensors
  • Resolution: 2–155 megapixel
  • Frame rate: up to 454 fps
  • Bit depth: 8 bit, 10 bit or 12 bit data output
  • Features: fixed pattern noise correction, field upgradable firmware, pixel defect correction
  • Lens: C-, F-, M42 or M72-Mount
  • Interface: CameraLink, CoaXPress or 10 GigE
  • Software: compatible with Common Vision Blox

Find the right model for your needs

Use the filters below to narrow down your selection based on your application requirements

À
À
À
À
Nom de produit Wavelength range Resolution (MP) Resolution Horizontal (Px) Resolution Vertical (Px) Frame rate (Hz) Lens mount Interface Sensor model Sensor type Scan type Pixel size (µm) Sensor format Sensor size diagonal (mm) Shutter type Dimension (width, mm) Dimension (height, mm) Dimension (depth, mm) Housing Weight (kg) Manufacturer
VIEWORKS VC-4MC-C180E0-CM
 Colour; Visible 4.2 2048 2048 179.5 C-Mount CameraLink CMV4000 CMOS area 5.5 1" 15.93 Global shutter/Prog scan 68 68 54 standard 0.420 Vieworks
VIEWORKS VC-4MC-M180E0-FM
 Monochrome; Visible 4.2 2048 2048 179.5 Nikon F-Mount CameraLink CMV4000 CMOS area 5.5 1" 15.93 Global shutter/Prog scan 68 68 83 standard 0.460 Vieworks
VIEWORKS VC-2MC-M340E0-CM
 Monochrome; Visible 2.2 2048 1088 337.6 C-Mount CameraLink CMV2000 CMOS area 5.5 2/3" 12.75 Global shutter/Prog scan 68 68 54 standard 0.420 Vieworks
VIEWORKS VC-4MC-M180E0-CM
 Monochrome; Visible 4.2 2048 2048 179.5 C-Mount CameraLink CMV4000 CMOS area 5.5 1" 15.93 Global shutter/Prog scan 68 68 54 standard 0.420 Vieworks
VIEWORKS VC-2MC-C340E0-CM
 Colour; Visible 2.2 2048 1088 337.6 C-Mount CameraLink CMV2000 CMOS area 5.5 2/3" 12.75 Global shutter/Prog scan 68 68 54 standard 0.420 Vieworks
VIEWORKS VC-2MC-M340E0-FM
 Monochrome; Visible 2.2 2048 1088 337.6 Nikon F-Mount CameraLink CMV2000 CMOS area 5.5 2/3" 12.75 Global shutter/Prog scan 68 68 83 standard 0.460 Vieworks
VIEWORKS VC-2MC-C340E0-FM
 Colour; Visible 2.2 2048 1088 337.6 Nikon F-Mount CameraLink CMV2000 CMOS area 5.5 2/3" 12.75 Global shutter/Prog scan 68 68 83 standard 0.460 Vieworks
VIEWORKS VC-4MC-M80E0-CM
 Monochrome; Visible 4.2 2048 2048 78.9 C-Mount CameraLink CMV4000 CMOS area 5.5 1" 15.93 Global shutter/Prog scan 68 68 54 standard 0.420 Vieworks
VIEWORKS VC-2MC-M150E0-FM
 Monochrome; Visible 2.2 2048 1088 148.5 Nikon F-Mount CameraLink CMV2000 CMOS area 5.5 2/3" 12.75 Global shutter/Prog scan 68 68 83 standard 0.460 Vieworks
VIEWORKS VC-4MC-C180E0-FM
 Colour; Visible 4.2 2048 2048 179.5 Nikon F-Mount CameraLink CMV4000 CMOS area 5.5 1" 15.93 Global shutter/Prog scan 68 68 83 standard 0.460 Vieworks
VIEWORKS VC-4MC-M80E0-FM
 Monochrome; Visible 4.2 2048 2048 78.9 Nikon F-Mount CameraLink CMV4000 CMOS area 5.5 1" 15.93 Global shutter/Prog scan 68 68 83 standard 0.460 Vieworks
VIEWORKS VC-4MC-C80E0-CM
 Colour; Visible 4.2 2048 2048 78.9 C-Mount CameraLink CMV4000 CMOS area 5.5 1" 15.93 Global shutter/Prog scan 68 68 54 standard 0.420 Vieworks
VIEWORKS VC-4MC-C80E0-FM
 Colour; Visible 4.2 2048 2048 78.9 Nikon F-Mount CameraLink CMV4000 CMOS area 5.5 1" 15.93 Global shutter/Prog scan 68 68 83 standard 0.460 Vieworks
VIEWORKS VC-2MC-M150E0-CM
 Monochrome; Visible 2.2 2048 1088 148.5 C-Mount CameraLink CMV2000 CMOS area 5.5 2/3" 12.75 Global shutter/Prog scan 68 68 54 standard 0.420 Vieworks
VIEWORKS VC-2MC-C150E0-CM
 Colour; Visible 2.2 2048 1088 148.5 C-Mount CameraLink CMV2000 CMOS area 5.5 2/3" 12.75 Global shutter/Prog scan 68 68 54 standard 0.420 Vieworks
VIEWORKS VC-2MC-C150E0-FM
 Colour; Visible 2.2 2048 1088 148.5 Nikon F-Mount CameraLink CMV2000 CMOS area 5.5 2/3" 12.75 Global shutter/Prog scan 68 68 83 standard 0.460 Vieworks
VIEWORKS VC-25MC-M30D0-FM
 Monochrome; Visible 26.2 5120 5120 30.8 Nikon F-Mount CameraLink VITA 25K CMOS area 4.5 Large format 32 Global shutter/Prog scan 68 68 83 standard 0.420 Vieworks
VIEWORKS VC-25MC-C30D0-FM
 Colour; Visible 26.2 5120 5120 30.8 M42 x 1; Nikon F-Mount CameraLink VITA 25K CMOS area 4.5 Large format 32 Global shutter/Prog scan 68 68 83 standard 0.420 Vieworks
VIEWORKS VC-12MX-M180E0-DIN-FM
 Monochrome; Visible 12.6 4096 3072 179.5 Nikon F-Mount CoaXPress CMV12000 CMOS area 5.5 Large format 28.16 Global shutter/Prog scan 80 80 101 standard 0.620 Vieworks
VIEWORKS VC-12MC-C65E0-FM
 Colour; Visible 12.6 4096 3072 65 Nikon F-Mount CameraLink CMV12000 CMOS area 5.5 Large format 28.16 Global shutter/Prog scan 68 68 83 standard 0.420 Vieworks
VIEWORKS VC-12MC-M65E0-FM
 Monochrome; Visible 12.6 4096 3072 65 Nikon F-Mount CameraLink CMV12000 CMOS area 5.5 Large format 28.16 Global shutter/Prog scan 68 68 83 standard 0.420 Vieworks
VIEWORKS VC-12MX-C180E0-DIN-FM
 Colour; Visible 12.6 4096 3072 179.5 Nikon F-Mount CoaXPress CMV12000 CMOS area 5.5 Large format 28.16 Global shutter/Prog scan 80 80 101 standard 0.620 Vieworks
VIEWORKS VC-25MX-M72D0-DIN-FM
 Monochrome; Visible 26.2 5120 5120 72 Nikon F-Mount CoaXPress VITA 25K CMOS area 4.5 Large format 32 Global shutter/Prog scan 80 80 101 standard 0.630 Vieworks
VIEWORKS VC-25MX-C72D0-DIN-FM
 Colour; Visible 26.2 5120 5120 72 Nikon F-Mount CoaXPress VITA 25K CMOS area 4.5 Large format 32 Global shutter/Prog scan 80 80 101 standard 0.630 Vieworks
VIEWORKS VC-25MX-C81D0-DIN-FM
 Colour; Visible 26.2 5120 5120 81 Nikon F-Mount CoaXPress Python 25K CMOS area 4.5 Large format 35 Global shutter 80 80 101 standard 0.630 Vieworks
VIEWORKS VC-25MX-M81D0-DIN-FM
 Monochrome; Visible 26.2 5120 5120 81 Nikon F-Mount CoaXPress Python 25K CMOS area 4.5 Large format 35 Global shutter 80 80 101 standard 0.630 Vieworks
VIEWORKS VC-12MX-C330F00-FM
 Colour; Visible 12.6 4096 3072 330 Nikon F-Mount CoaXPress CMV12000 CMOS area 5.5 Large format 28.16 Global shutter 90 90 110 standard 0.745 Vieworks
VIEWORKS VC-101MX-M9H00
 Monochrome; Visible 101 11648 8742 8.1 M72 x 0.75 CoaXPress IMX461 CMOS area 3.76 Large format 55 Rolling shutter 90 90 92.5 standard 0.800 Vieworks
VIEWORKS VC-151MX-M6H00
 Monochrome; Visible 151 14192 10640 6.2 M72 x 0.75 CoaXPress IMX411 CMOS area 3.76 Large format 66.7 Rolling shutter 100 100 92.5 standard 1.070 Vieworks
VIEWORKS VC-101MX-C9H00
 Colour; Visible 101 11648 8742 8.1 M72 x 0.75 CoaXPress IMX461 CMOS area 3.76 Large format 55 Rolling shutter 90 90 92.5 standard 0.800 Vieworks
VIEWORKS VC-151MX-C6H00
 Colour; Visible 151 14192 10640 6.2 M72 x 0.75 CoaXPress IMX411 CMOS area 3.76 Large format 66.7 Rolling shutter 100 100 92.5 standard 1.070 Vieworks
VIEWORKS VC-101MC-M8H00
 Monochrome; Visible 101 11648 8742 8.1 M72 x 0.75 CameraLink IMX461 CMOS area 3.76 Large format 55 Rolling shutter 100 100 92.5 standard 1.070 Vieworks
VIEWORKS VC-25MC-M31I0
 Monochrome; Visible 25 5120 5120 31 C-Mount CameraLink GMAX0505 sCMOS area 2.5 1.1" 18.1 Global shutter 55 55 57 standard 0.215 Vieworks
VIEWORKS VC-25MC-C31I0
 Colour; Visible 25 5120 5120 31 C-Mount CameraLink GMAX0505 sCMOS area 2.5 1.1" 32.58 Global shutter 50 50 57 standard 0.215 Vieworks
VIEWORKS VC-25MX2-M150I10-CM
 Monochrome; Visible 26.2 5120 5120 150.2 C-Mount CoaXPress GMAX0505 CMOS area 2.5 Medium format 18.1 Global shutter 80 80 69.4 standard 0.560 Vieworks
VIEWORKS VC-25MX2-C150I10-CM
 Colour; Visible 26.2 5120 5120 150.2 C-Mount CoaXPress GMAX0505 CMOS area 2.5 Medium format 18.1 Global shutter 80 80 69.4 standard 0.560 Vieworks
VIEWORKS VC-65MX2-M71I10-FM
 Monochrome; Visible 65.4 9344 7000 71.1 Nikon F-Mount CoaXPress GMAX3265 CMOS area 3.2 Large format 37.4 Global shutter 80 80 105 standard 0.750 Vieworks
VIEWORKS VC-65MX2-C71I10-FM
 Colour; Visible 65.4 9344 7000 71.1 Nikon F-Mount CoaXPress GMAX3265 CMOS area 3.2 Large format 37.4 Global shutter 80 80 105 standard 0.750 Vieworks
VIEWORKS VC-4MX-M144F00-CM
 Monochrome; Visible 4 2048 2048 144 C-Mount CoaXPress CMV4000 CMOS area 5.5 1" 15.93 Global shutter/Prog scan 40 40 41 standard 0.200 Vieworks
VIEWORKS VC-17MC-M48H00-FM
 Monochrome; Visible 16.8 5440 3076 48.4 Nikon F-Mount CameraLink IMX387 CMOS area 3.45 4/3" 21.5 Global shutter 68 68 105 standard 0.537 Vieworks
VIEWORKS VC-17MC-C48H00-FM
 Colour; Visible 16.8 5440 3076 48.4 Nikon F-Mount CameraLink IMX387 CMOS area 3.45 4/3" 21.5 Global shutter 68 68 105 standard 0.537 Vieworks
VIEWORKS VC-31MC-M26H00-FM
 Monochrome; Visible 31.4 6464 4852 26.2 Nikon F-Mount CameraLink IMX342 CMOS area 3.45 APS-C 27.9 Global shutter 68 68 105 standard 0.537 Vieworks
VIEWORKS VC-31MC-C26H00-FM
 Colour; Visible 31.4 6464 4852 26.2 Nikon F-Mount CameraLink IMX342 CMOS area 3.45 APS-C 27.9 Global shutter 68 68 105 standard 0.537 Vieworks
VIEWORKS VC-17MX-C61H00-FM
 Colour; Visible 16.8 5440 3076 61.3 Nikon F-Mount CoaXPress IMX387 CMOS area 3.45 4/3" 21.5 Global shutter 68 68 105 standard 0.550 Vieworks
VIEWORKS VC-17MX-M61H00-FM
 Monochrome; Visible 16.8 5440 3076 61.3 Nikon F-Mount CoaXPress IMX387 CMOS area 3.45 4/3" 21.5 Global shutter 68 68 105 standard 0.550 Vieworks
VIEWORKS VC-31MX-M35H00-FM
 Monochrome; Visible 31.4 6464 4852 35.4 Nikon F-Mount CoaXPress IMX342 CMOS area 3.45 APS-C 27.9 Global shutter 68 68 105 standard 0.550 Vieworks
VIEWORKS VC-31MX-C35H00-FM
 Colour; Visible 31.4 6464 4852 35.4 Nikon F-Mount CoaXPress IMX342 CMOS area 3.45 APS-C 27.9 Global shutter 68 68 105 standard 0.550 Vieworks
VIEWORKS VC-25M10G-M41I00-CM
 Monochrome; Visible 25 5120 5120 41.7 C-Mount Gigabit Ethernet GMAX0505 sCMOS area 2.5 1.1" 18.1 Global shutter 68 68 74 standard 0.460 Vieworks
VIEWORKS VC-25M10G-C41I00-CM
 Colour; Visible 25 5120 5120 41.7 C-Mount Gigabit Ethernet GMAX0505 sCMOS area 2.5 1.1" 18.1 Global shutter 68 68 74 standard 0.460 Vieworks
VIEWORKS VC-5MX2-M289I10-CM
 Monochrome; Visible 5 2592 2160 289 C-Mount CoaXPress GMAX2505 CMOS area 2.5 1/2" 8.38 Global shutter/Prog scan 50 50 91 standard 0.270 Vieworks
VIEWORKS VC-9MX2-M262I10-CM
 Monochrome; Visible 9 4192 2160 262 C-Mount CoaXPress GMAX2509 CMOS area 2.5 2/3" 11.8 Global shutter/Prog scan 50 50 91 standard 0.270 Vieworks
VIEWORKS VC-61MX-C18H00-FM
 Colour; Visible 61 9568 6380 18 Nikon F-Mount CoaXPress IMX455 CMOS area 3.76 Large format 43.2 Rolling shutter 80 80 107 standard 0.745 Vieworks
VIEWORKS VC-5MX2-C289I10-CM
 Colour; Visible 5 2592 2160 289 C-Mount CoaXPress GMAX2505 CMOS area 2.5 1/2" 8.38 Global shutter/Prog scan 50 50 91 standard 0.270 Vieworks
VIEWORKS VC-9MX2-C262I10-CM
 Colour; Visible 9 4192 2160 262 C-Mount CoaXPress GMAX2505 CMOS area 2.5 2/3" 8.38 Global shutter/Prog scan 50 50 91 standard 0.270 Vieworks
VIEWORKS VC-18MX2-M132I10-CM
 Monochrome; Visible 18 4480 4096 132 C-Mount CoaXPress GMAX2518 CMOS area 2.5 1" 15.18 Global shutter/Prog scan 50 50 91 standard 0.270 Vieworks
VIEWORKS VC-18MX2-C132I10-CM
 Colour; Visible 18 4480 4096 132 C-Mount CoaXPress GMAX2518 CMOS area 2.5 1" 15.18 Global shutter/Prog scan 50 50 91 standard 0.270 Vieworks
VIEWORKS VC-21MX2-C230I00-FM
 Colour; Visible 20.9 5120 4096 226 Nikon F-Mount CoaXPress GSPRINT4521 CMOS area 4.5 N/A 29.51 Global shutter 80 80 104 standard 0.750 Vieworks
VIEWORKS VC-21MDF-M460I00-FM
 Monochrome; Visible 20.9 5120 4096 454 Nikon F-Mount CoaXPress GSPRINT4521 CMOS area 4.5 N/A 29.51 Global shutter 68 68 135 standard N/A Vieworks
VIEWORKS VC-21MDF-C460I00-FM
 Colour; Visible 20.9 5120 4096 454 Nikon F-Mount CoaXPress GSPRINT4521 CMOS area 4.5 N/A 29.51 Global shutter 68 68 135 standard N/A Vieworks
VIEWORKS VC-21MDF-M460I00-HS-FM
 Monochrome; Visible 20.9 5120 4096 454 Nikon F-Mount CoaXPress GSPRINT4521 CMOS area 4.5 N/A 29.51 Global shutter 68 68 135 standard N/A Vieworks
VIEWORKS VC-21MDF-C460I00-HS-FM
 Colour; Visible 20.9 5120 4096 454 Nikon F-Mount CoaXPress GSPRINT4521 CMOS area 4.5 N/A 29.51 Global shutter 68 68 135 standard N/A Vieworks
VIEWORKS VCS-14MX2-C340I
 Colour; Visible 14.1 4608 3072 338 M42 x 1 CoaXPress GSPRINT5514 BSI CMOS N/A 5.5 N/A 30.54 Global shutter 68 68 83.2 standard 0.460 Vieworks
VIEWORKS VCS-14MX2-M340I
 Monochrome 14.1 4608 3072 338 M42 x 1 CoaXPress GSPRINT5514 BSI CMOS N/A 5.5 N/A 30.54 Global shutter 68 68 83.2 standard 0.460 Vieworks
VIEWORKS VC-51MX2-C30I00-M58
 Colour; Visible 51 8416 6032 30.4 M58 x 0.75 CoaXPress GMAX4651 CMOS area 4.6 N/A 47.63 Global shutter 68 80 76 standard 0.410 Vieworks

Pourquoi choisir Vieworks - VC ?

Ultra high resolution and high speed

The Vieworks VC family is a series of CMOS cameras for machine vision applications that offer high resolutions up to 151 megapixels and high speeds up to 450 fps.

Improved usability

The programmable camera makes it easier to update the firmware in machine vision. The VC Series supports CameraLink and CoaXPress interfaces.

Latest CMOS sensor technology

The VC series offers you the latest sensor technology designed to ensure perfect compatibility between the camera-specific hardware and software, with enhanced safety right across the board. This provides high data volumes, precise and accurate image reproduction.
