JAI GOX-16205C-PGE
SKU#:
53269
Small and reliable industrial camera
Hinweis: Das tatsächliche Produkt kann von der Abbildung abweichen!
You can find downloads in the corresponding product series:
JAI - Go-X
Kontakt aufnehmen
Preise anfragen
Irrtümer und Änderungen sind vorbehalten. Es gelten unsere Allgemeinen Geschäftsbedingungen. Wir beliefern ausschließlich Unternehmenskunden.
Product Features
| Attributes | |
|---|---|
| Bit depth | 10, 12, 8 |
| Connector a: video | RJ45 - (H) - Female |
| Connector b: power | Hirose 6-pin |
| Connector c: I/O | HIROSE - 6-pin - Female |
| Dimension (depth, mm) | 55 |
| Dimension (height, mm) | 29 |
| Dimension (width, mm) | 29 |
| Frame rate (Hz) | 7 |
| Resolution Horizontal (Px) | 5328 |
| Housing | small |
| Interface | Gigabit Ethernet |
| Interface configuration | 1 GigE |
| Lens mount | C-Mount |
| Numbers of connectors (Video) | 1 |
| Operating temperature (°C) | -5 - 45 |
| Output formats | Mono10, Mono12, Mono8 |
| Pixel clock (MHz) | 74 |
| Pixel size (µm) | 2.74 |
| Power consumption (W) | 2.7 |
| Power supply voltage (VDC) | 10 - 25 |
| Resolution (MP) | 16.2 |
| Scan type | area |
| Sensor configuration | Single sensor |
| Sensor format | 1.1" |
| Sensor model | IMX542 |
| Sensor size diagonal (mm) | 16.81 |
| Sensor type | CMOS |
| Shutter type | Global shutter |
| Software CameraSuite | yes |
| Software driver CVB | yes |
| Wavelength range | Colour, Visible |
| Storage temperature (°C) | -25 - 60 |
| Resolution Vertical (Px) | 3040 |
| Weight (kg) | 0.065 |
- Sensor: Sony Pregius and Pregius S CMOS sensors with global shutter or rolling shutter and square pixels
- Resolution: up to 24.5 MP
- Digital Output 8/10/12 bit
- Frame rate: up to 162 fps in 8-bit mode
- Features: ROI, image flipping and mirroring, 2x2 decimation, blemish compensation and shading correction, two different sequencer modes and automatic level control function
- Interface: USB3 Vision, GigE Vision, CoaXPress
- Lens mount: C-mount, CS-mount
- Dimensions: 29 x 29 x 55 mm
- Industrial proven with 80G shock and 10G vibration and MTBF > 200k hours
- 6 years full warranty
