LMI - Gocator 2D
The LMI Gocator 2D Smart Camera provides a complete solution for high-speed 2D measurement and inspection in demanding factory automation environments. Combining global shutter imaging, integrated lighting control, NVIDIA powered edge processing, and scalable web-based software, it delivers fast, accurate results -without external PCs or cloud infrastructure.
Key Features
- Imaging: Up to 12 MP, global shutter
- Speed: Up to 84 fps (5 MP) / 41 fps (12 MP), burst mode without processing
- Processing: NVIDIA Jetson Orin NX (on-device AI)
- Software: GoPxL web-based UI
- Tools: Alignment, edge, blob, barcode, OCR, anomaly detection
- Interfaces Gigabit Ethernet, M12 industrial connectors
- Protection IP67 industrial housing
- Lens: C-mount
Find the right model for your needs
Use the filters below to narrow down your selection based on your application requirements
| Produktname | Manufacturer | Pixel size (µm) | Resolution (MP) | Sensor format | Sensor model | Sensor size diagonal (mm) | Sensor type | Shutter type | Software type | Wavelength range | Technology | Frame rate (Hz) | Resolution Horizontal (Px) | IP rating | Lens mount |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| LMI Technologies | 2.74 | 5 | 1/1.8" | IMX548 | 8.9 | CMOS | Global shutter | N/A | Monochrome | Smart | 84 | 2464 | IP67 | C-Mount | |
| LMI Technologies | 2.74 | 5 | 1/1.8" | IMX548 | 8.9 | CMOS | Global shutter | N/A | Colour | Smart | 84 | 2464 | IP67 | C-Mount | |
| LMI Technologies | 2.74 | 12 | 1/1.1" | IMX545 | 14 | CMOS | Global shutter | N/A | Monochrome | Smart | 41 | 4128 | IP67 | C-Mount | |
| LMI Technologies | 2.74 | 12 | 1/1.1" | IMX545 | 14 | CMOS | Global shutter | N/A | Colour | Smart | 41 | 4128 | IP67 | C-Mount |
Warum LMI - Gocator 2D?
Integrated Powerhouse
Seamless image processing with the combined strength of Alvium camera technology and NVIDIA Orin, delivering unparalleled performance for complex vision tasks.
Versatile Resolution Options
Choose from 5 MP and 12 MP resolutions, along with monochrome and color options, ensuring that Alecs meets the specific needs of your application for optimal image clarity.
Robust and Reliable Design
The IP67 rated housing provides exceptional protection against dust and water, ensuring longevity and reliability in harsh industrial environments.
AI-Ready for Advanced Applications
Unlock the potential of machine learning with a system designed for easy deployment of sophisticated AI algorithms, enhancing your capabilities in object detection, tracking, and classification.
Seamless Compatibility with GoPixl
Effortlessly integrate Gocator 2D into your existing workflows with full compatibility with GoPixl, streamlining your development process and saving time.
