METAPHASE - Collimated Line Lights
Powerful line lights to overcome long distances between illumination and object.
Key Features
- Colour: white, blue, green, red, IR 1650 nm, UV 365 or 395 nm, but also RGB and SWIR wavelengths on demand
- Dimensions: from 5" to 120" in 5" increments
- Miscellaneous: working distance up to 2 m
Find the right model for your needs
Use the filters below to narrow down your selection based on your application requirements
| Produktname | Beam angle | Connectors | Dominant wavelength (nm) | Emitting surface height (mm) | Emitting surface inner diameter (mm) | Emitting surface outer diameter (mm) | Emitting surface width (mm) | Intensity control method | IP rating | LED risk group | Light colour | Light distribution | Lighting geometry | Lighting technique | Manufacturer | Smart | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| line | N/A | N/A | 255 | N/A | N/A | 254 | N/A | N/A | N/A | White | direct | line light | frontlight | Metaphase | no | N/A | |
| line | N/A | 630 | 24 | N/A | N/A | 254 | N/A | N/A | N/A | Red | direct | line light | frontlight | Metaphase | no | N/A | |
| line | N/A | N/A | 24 | N/A | N/A | 281 | N/A | N/A | N/A | White | direct | line light | frontlight | Metaphase | no | N/A | |
| line | N/A | N/A | 24 | N/A | N/A | 635 | N/A | N/A | N/A | White | direct | line light | frontlight | Metaphase | no | N/A | |
| collimated | N/A | N/A | 24 | N/A | N/A | 667 | N/A | N/A | N/A | White | direct | line light | frontlight | Metaphase | no | N/A | |
| line | N/A | N/A | 24 | N/A | N/A | 508 | N/A | N/A | N/A | White | direct | line light | frontlight | Metaphase | no | N/A | |
| collimated | N/A | N/A | 24 | N/A | N/A | 158 | N/A | N/A | N/A | White | direct | line light | frontlight | Metaphase | no | 0.635 | |
| line | N/A | N/A | 24 | N/A | N/A | 102 | N/A | N/A | N/A | White | direct | line light | frontlight | Metaphase | no | N/A | |
| collimated | N/A | N/A | 24 | N/A | N/A | 1175 | N/A | N/A | N/A | White | direct | line light | frontlight | Metaphase | no | N/A | |
| collimated | N/A | N/A | 24 | N/A | N/A | 80 | N/A | N/A | N/A | White | direct | line light | frontlight | Metaphase | no | N/A | |
| collimated | N/A | N/A | 24 | N/A | N/A | 508 | N/A | N/A | N/A | White | direct | collimated illumination; line light | frontlight | Metaphase | no | N/A | |
| collimated | N/A | 850 | 24 | N/A | N/A | 80 | N/A | N/A | N/A | IR; White | direct | line light | frontlight | Metaphase | no | N/A | |
| collimated | N/A | 1650 | 24 | N/A | N/A | 80 | N/A | N/A | N/A | IR | direct | line light | frontlight | Metaphase | no | N/A |
Warum METAPHASE - Collimated Line Lights?
Special lens design
Metaphase uses a proprietary collimated lens technology for low divergence angle illumination. This results in a well structured beam of light even at longer working distances.
Sophisticated cooling options
The MetaBright collimated line lights (MB-CLL) are housed in a small profile, even though actively cooled. UX collimated line lights (UX-CLL) are passively cooled with options for compressed air or liquid cooling. This is useful for high intensity applications or in harsh environments where fans cannot be used.
Available in different sizes and wavelengths
Available in 5" increments starting from 5" to 120". LED options range from white, blue, green, red, IR 850 nm, UV 365 or 395 nm to RGB. Also available with SWIR LEDs (1050, 1200, 1300,1450, 1550 or 1650 nm).
