TELEDYNE FLIR FG-P5G-120S6M-C
SKU#:
62061
The Cool Performer.
Hinweis: Das tatsächliche Produkt kann von der Abbildung abweichen!
Die Downloads finden Sie unter der entsprechenden Produktserie:
Teledyne FLIR - Forge 5 GigE
List Price
Your Discount
Your Price
Product not available in your country
Preis und Verfügbarkeit auf Anfrage
Kontakt aufnehmen
Preise anfragen
Errors and changes excepted. Our general terms and conditions apply. We supply exclusively to corporate customers.
Product Features
| Attributes | |
|---|---|
| Wavelength range | Monochrome, Visible |
| Resolution (MP) | 12.4 |
| Resolution Horizontal (Px) | 4096 |
| Resolution Vertical (Px) | 3000 |
| Frame rate (Hz) | 50 |
| Lens mount | C-Mount |
| Interface | Gigabit Ethernet |
| Sensor model | IMX545 |
| Sensor type | CMOS |
| Scan type | area |
| Pixel size (µm) | 2.74 |
| Sensor format | 1/1.1" |
| Sensor size diagonal (mm) | 13.91 |
| Shutter type | Global shutter |
| Dimension (width, mm) | 29 |
| Dimension (height, mm) | 44 |
| Dimension (depth, mm) | 74 |
| Housing | closed housing |
| Weight (kg) | 0.132 |
| Manufacturer | Teledyne FLIR |
| Active sensor size (horizontal, mm) | 11.2 |
| Active sensor size (vertical, mm) | 12.6 |
| Bit depth | 10, 12, 8 |
| Certificates | CE, FCC, REACH, RoHS |
| Connector a: video | RJ45 (H) |
| Connector b: power | Hirose 8-pin |
| Filter | no |
| Flange focal distance | 17.526 |
| Interface configuration | 1 GigE, 2,5 GigE, 5 GigE |
| Numbers of connectors (Video) | 1 |
| Operating temperature (°C) | -20 - 65 |
| Power consumption (W) | 8.5 |
| Software CameraSuite | yes |
| Storage temperature (°C) | -30 - 60 |
- Superior thermal management: Up to 20°C cooler operation
- Extended temperature range: -20°C to 65°C (housing)
- All-metal body: No auxiliary cooling required
- Resolution: Up to 24.5 Megapixel (Sony Pregius Gen 4)
- Burst mode: Up to 10Gb/s with 500MB image buffer
- Max frame rate: 122 FPS (163 FPS burst)
- Standard lens mount: C-mount
- Sensor type: CMOS (Sony Highspeed Sensors)
- Data interface: 1, 2.5, and 5 Gbit/s Ethernet
- Spectrum: colour / monochrome
- Power over Ethernet (PoE) support
